iMEX i99R Rotating Laser Level – Red Beam

The new IMEX i99R laser level offers everything that the contractor and tradesman needs in a rotating laser level. The auto dial in grade, allows for a % or slope to be dialled in using the simple remote keypad for fast setup and total job control. Combined with this is the rugged construction and high-visibility casing giving extra water and dust proofing for all site conditions.

  • 600m diameter range. +/- 1.5mm over 30m Accuracy.
  • Self levelling, resets if bumped or moved.
  • 9Ah lithium-ion battery – approx. 40 hours run time
  • USB quick charge port with car charger
  • LRX10 Digital Detector in mm reading (German made)
  • 90mm Detector reading ultra fine, fine, medium, course and ultra course.
  • Fast and accurate set-up time. Re-sets if unit is bumped or moved



Request more information about this product
Categories:

Description

  • Remote Control Panel – allows grade or other functions to be carried out up to 20m away from the instrument,for true one-man operation and greater efficiency.
  • Hi-Visibility Case – unique Imex feature, easy to see on the busiest construction site, minimises the risk of the unit being bumped, increasing safety and accuracy.
  • Plumb Spot – Top and bottom plumb spot beam to assist in set ups over a point.
  • Horizontal/Vertical – Dual function,instrument works in horizontal plane or vertical plane when turned on its side. Invaluable for set-out, alignment, point transfer or interior set-outs.
  • Scan Mode – Allows for part beam rotation in selected working environments, i.e. on interior walls, busy work-sites where other laser interference may be present.

I99R SPECIFICATIONS

Imex i99R 012-I99R -Specifications
Self Levelling Range +/-5°
Working Distance 600m Diameter
Function Horizontal/Vertical
Scan Mode Yes, 0°, 10°, 45°, 90°, 180°
Slope Mode Yes – Auto dial in dual grade to 10%
Accuracy 1.5mm @ 30m
Rotation Speeds 0, 60, 120, 300, 600 rpm
Waterproof/Shockproof IP66
Light Source Red diode 635nm Class II
Power 9 Ah 3.7v lithium-ion
Detector LRX10 Double Sided
Working time – continuous use 40hrs approx Red
Charging Time 4 hours in unit or removed from unit
USBC Charging Yes; including 12v car charger
High Wind Sensitivity Re-set Yes
Remote Control Yes, iCR9
Weight – Unit Only 2.5kg
Detector – German Made LRX10 Double Sided
Detector – Pick Up 90mm -30mm to +60mm
Detector Reading Ultrafine – 0.5mm | Fine – 1.0mm | Medium – 2.0mm | Course – 5.0mm | Ultra Course – 10.0mm
Detector Power 1-AA > 50 hrs run
Inclusions Unit, LRX10 Detector, Remote control unit, USB cable, 9.0 Ah Lithium battery, Car charger, target plate, hard carry case
