iMEX LX22 Green Crossliner

Rp4,377,590.12 inc GST

The Imex LX22G crossline laser features ultra-bright green beam technology with one horizontal and one vertical line, plumb up and plumb down. Series II features an all-new sturdy magnetic bracket enabling quick release of the laser without screws to hold it in place. The new 5.2Ah lithium battery pack gives you plenty of run time to keep up with your busy day on site, featuring USB-C fast charge. Locally calibrated and tough to withstand the knocks and bumps on site, the LX22G Series II has rubberised housing for a comfortable, non-slip grip.

  • NEW quick release magnetic bracket – no screws to hold laser in place
  • NEW 5.2Ah lithium battery pack – swaps to all LX series II models. OPTION for LX22 – comes with AA battery pack as standard
  • NEW rugged housing with non-slip rubberised moulding
  • High visibility green beam technology
  • Plumb up, plumb down
  • 1 horizontal, 1 vertical line
  • Pulse mode for detector
  • Self levelling

This product is only available to buy online in Singapore, for another country please request more information!

FREE DELIVERY FOR ORDERS OVER S$400 (Singapore Only)

2 in stock

Categories:
SKU: 012-LX22S

Description

LX22G SPECIFICATIONS

In keeping with Imex’s legendary laser and measuring equipment offer, the LX22G Series II comes with a full 3 year warranty and a world first in this price point, a full Calibration Certificate, verifying its accuracy and serviceability.

Imex LX22G Green Beam Specifications
Self levelling range 4° ± 1
Out of level indication  laser blinks on/off
Laser lines / dots  1 vertical, 1 horizontal line, plumb up/down dots
Laser accuracy   ±3mm @10m
Laser class       Class 2
Laser wavelength   635 ± 10 nm
Laser distance 10m light-dependent
Laser distance with optional detector  50m
Power source  5.2 Ah lithium ion
Charging  type USB-C
Run time- both beams        10 hrs
Control switch   1 button, pendulum lock
IP Rating     IP54
Operating temperature   -10° to +50°C
Storage temperature     -20° to +70° C
Kit Inclusions lithium battery,alkaline batteries,  magnetic bracket operating manual, plastic carry case

See manufacturer page
