MULTI-BAND RTK GNSS MODULE FOR PRECISE NAVIGATION AND UAV MAPPING
For precise UAV mapping with less GCPs.
The Reach M2 is a compact and easy-to-use RTK GNSS module that connects to a camera and records the location of each photo. With an update rate of up to 20 Hz, the Reach M2 produces highly detailed and accurate georeferenced data sets.
GPS/QZSS L1C/A, L2C
GLONASS L1OF, L2OF
BeiDou B1I, B2I
Galileo E1-B/C, E5b
Static horizontal 4mm + 0.5 ppm
Static vertical 8mm + 1 ppm
Kinematic horizontal 7mm + 1 ppm
Kinematic vertical 14mm + 1 ppm
LoRa radio (sold separately) 868/915MHz (up to 8km)
Wi-Fi 802.11b/g/n
Bluetooth 4.0/2.1 EDR
Ports: USB, UART, Event
NTRIP and RTCM3 corrections
NMEA and LLH/XYZ position output
RINEX logs with update rate up to 20Hz
16GB internal storage
